Maxi Master Floodlight Gen2
PRODUCT FEATURES
- Rated life: L70/B50 50000hrs
- LED: CCT 4000K, CRI>80, 7 SDCM
- Beam angle: Symmetrical, Asymmetrical
- Driver: Integral, Non-Dim
- Rating: IP65, IK08, Class I
- Operating temperature: -10°C to +40°C
- Housing: Die-cast LM6 aluminium (low copper content <0.1%)
- Finishing: Black, Powder coating
- Diffuser/Lens: Tempered glass, Clear
- Connection/Installation: 1.0m flying lead, Galvanised trunnion arm with integrated aiming protractor
- Accessory: Wire guard
- Warranty: 5 year
APPLICATIONS
Surface mount, Internal, ExternalCarpark, Commercial, Industrial, Security lighting
MAXI MASTER FLOODLIGHT 100W 4K ASYMMETRICAL
CODE: MML100ASystem Power (W)
102W
Lumen Output
11400lm
Lumens per Watt
112lm/W
Color Temperature
4000K
Beam Distribution
Asymmetrical
Line Current (A)
0.43A
Dimensions
L318 x W60 x H372 mm
Luminaire
Aluminium
MAXI MASTER FLOODLIGHT 100W 4K SYMMETRICAL
CODE: MML100SSystem Power (W)
102W
Lumen Output
12300lm
Lumens per Watt
121lm/W
Color Temperature
4000K
Beam Distribution
Symmetrical
Line Current (A)
0.43A
Dimensions
L318 x W60 x H372 mm
Luminaire
Aluminium
MAXI MASTER FLOODLIGHT 200W 4K ASYMMETRICAL
CODE: MML200ASystem Power (W)
201W
Lumen Output
22100lm
Lumens per Watt
110lm/W
Color Temperature
40000K
Beam Distribution
Asymmetrical
Line Current (A)
0.84A
Dimensions
L342 x W60 x H475 mm
Luminaire
Aluminium
MAXI MASTER FLOODLIGHT 200W 4K SYMMETRICAL
CODE: MML200SSystem Power (W)
201W
Lumen Output
24100lm
Lumens per Watt
120lm/W
Color Temperature
400K
Beam Distribution
Symmetrical
Line Current (A)
0.84A
Dimensions
L342 x W60 x H475 mm
Luminaire
Aluminium
MAXI MASTER FLOODLIGHT 300W 4K ASYMMETRICAL
CODE: MML300ASystem Power (W)
293W
Lumen Output
34300lm
Lumens per Watt
117lm/W
Color Temperature
4000K
Beam Distribution
Asymmetrical
Line Current (A)
1.28A
Dimensions
L529 x W65 x H444 mm
Luminaire
Aluminium
MAXI MASTER FLOODLIGHT 300W 4K SYMMETRICAL
CODE: MML300SSystem Power (W)
296W
Lumen Output
35700lm
Lumens per Watt
121lm/W
Color Temperature
4000K
Beam Distribution
Symmetrical
Line Current (A)
1.28A
Dimensions
L529 x W65 x H444 mm
Luminaire
Aluminium
